I have detailed photos of my DD15 amp wiring. I did this when I sent mine in for repair. Give me your email, and I will send them to you. They should help a lot.
John
Velodyne DD15 - internal wiring
My DD15 stopped working (just back from repair).
Took the plate amp out and checked both fuses (good), power going to the board.
I DID find 2 wires (3 pin and 4 pin) inside the box that were NOT connected.
Can someone tell me where they are supposed to connect to the amp?
10 responses Add your response
@koestner Thank you! I message with contact email.
|
@dekay Yes, EBC. But it alway takes a few days (emailed Thursday), and not sure if they have sub specific wiring photos. The photos I took prior to sending in last time do not show. |
@koestner they don't allow contact info. Can you upload to this facebook? https://www.facebook.com/KraftwerkTurbo |
@dekay Thanks. downloaded one that might help. Found the 4 pin with thick black wire going to botto 4 pin, now connected. Have NOT found a come for the other thick black cable with 3 pin connector.
|
