Searching for Diatone DS-505 crossover schematic


Hello, I have searched online without success. Hoping to find the schematic for the Diatone DS-505's. I'm away from home for another week and wanted to come up with a budget and possibly make an order. Thanks, David

justgotohm
Why?  It is a relatively simple 2nd order based on the actual impedance of the specific drivers.

Yea, it's 2nd order. BUT>>>> which impendence? Diatone did an amazing job of selecting just the correct values and types to accommodate the changing impedances of those amazing drivers.

I'll look for it; I have the most complete library of these speaker systems in the U.S.
