MIT oracle v2.1 question.

"Wide, Ultra wide, etc... only pertains to the older MIT series speaker cables."
And to the new MAX rev.2's; using the ultra-wide for Spectral

Matrixdude,
Thanks, I have a better understanding of the MIT line now. I want to do some rearranging so I need about a 4m length balanced cable.

Mike

Wide, Ultra wide, etc... only pertains to the older MIT series speaker cables.

Jimf,
Thank you very much, this clears up a lot of my questions.
I need a balanced cable, I might go with the V2.2 if I can find it.
I'm used to using cables like Tara 0.8, Nordost Valhalla and Synergistic Tesla Apex. I wonder how the MIT Oracle v2.2 sound is compered to these cables?

Mike

Hi Mjglo,

I have MIT Oracle V2.1 interconnects in my system and I am using a pair between the phono stage and the preamp. The interconnect has an Adjustable Impedance System which is controlled by a sliding switch set to the following positions:

Low 5-50 KOhms
Mid 40-100 KOhms
High 90 KOhms and up

These positions can help you optimize the best setting between the two components. The IC switch is to be set to the input impedance of the component being connected to. In this case your preamp. A quick check on google of Audio Research archives listed the input impedance of the Ref.2 MkII preamp as 132 KOhms balanced or 66 KOhms SE (RCA).

So if using Balanced interconnects you would probably select the High position. If using RCA interconnects then Mid would probably be selected according to this MIT matching system.

Not sure about the Ultra Wide, Wide and EX designations. This might pertain only to the speaker cables. I do know that before the Adjustable Impedance System I had bought some MIT MI-330 Shotgun IC's and had to specify Low, Med or High when ordering.
