Well Tempered Ref. Arm

I agree with HiFiharv. The platter is concave so the record slopes toward the spindle when clamped. The cartridge therfore should be slightly tilted to maintain the proper azimuth with the record groove. It would be normal then for the paddle to be slightly tilted in the fluid cup and NOT perfectly horizontal.

Maprik,
I have the arm on a VPI Super Scoutmaster with a Superplatter that appears to be perfectly flat. So, I don't believe this is the reason for the apparently skewed paddletop (I still stand by my explanation of 4/17/09). Furthur thoughts anyone?

I recently acquired a Well Tempered Labs Record Player. Circe early 90's. It's not the reference arm, it's the more plain, silver finished one fitted to the Stanalg WTLRP.

And i can report that my paddle is also cocked to the left (It's left side is higher when viewed from the user position)

This is the case even though the azimuth is correct. Which is to day it seems the arm tube is rotated as it passes through the paddle assembly. i have not tried to straighten it out.

I'll be interested to see if anyone comes along with advice.

Was hoping that there might be some more current observations on this point.
