VR-4jr / How to wire?

Take out the datalink and connect directly to the post on the mid/tweeter. All the datalink does is connect the top set of post on the base unit to the mid/tweeter. The reason for this is so you can use bi-wire cables with short tails.

Later,

Hi, I'm a dealer and have experimented quite a bit with the VRjr's and the wiring and noted the differences heard with each approach.

The Shotgun approach is, by a significant margin, the most transparent, coherent and lifelike of the ways. Wired this way the system has an uncanny ability to portray the musical event.

The datalink is very useful to bi-wire the system when your bi-wire cables have short pigtails and thus will not reach to the upper mid-tweeter connections on the upper unit. Using the datalink (without jumper plates) is the next best way to wire the system. This way does sacrifice some transparency and directness but still has very high level of coherency.

Single wiring is the most basic way to wire the system. Install the jumper plates and datalink as instructed in the manual. I would recommend to connect the speaker cables from your amplifier to the lower woofer posts. This method does give up a little more transparency but it is still very good.

In my experience the bottom line is to shotgun run this speaker to the lower woofer post on bass module and to mid-tweeter posts on the upper module.

Hope this helps.

Tony

Tony,

When you shotgun as described do you remove the jumper plates? Thanks,

--Joe

i am here in 2024 waiting for the answer to the last question as I just got my Jrs today

I like shotgun biwire( two speaker cables to each speaker...one to the MT and one to the bass) Also I like to mix and match...experiment around...maybe copper to one and silver plated or silver to the other. These speakers repond well to biwire and bi-amp. You read some people poopooing biwire...but seems to work for me. Also experiemented with biwire jumpers from each cabinet along with shotguns. Jury is still out as to whether this is worth it. Everyones system is different and you just have to try stuff untill you are happy....ooops we are never happy. lol
